Flexible & Intuitive. Precise 2D CAD drawing software.

MacDraft lets you design with confidence

Fully-scaled and layered environment, precise guides and dimensioning, drag-and-drop symbols and intuitive vector drawing tools.

Sketch, draw and present. The ultimate 2D CAD software from start to finish. Native to macOS, built with the latest technologies and designed for the future, MacDraft 8 is a feature-rich solution, that gives you all the tools you need for a truly collaborative and flexible 2D CAD experience. Designed for architects, engineers and construction services as well as professional CAD users, designers, educators and hobbyist. MacDraft will give you the confidence and flexibility to design anything.

Buy Now

Try for Free

What’s new?

See all new features

Explore the latest features, tools and options available in the MacDraft Professional 8 tool-sets. MacDraft delivers a smooth and fast design process through the use of industry-leading technologies, intuitive workflow and a familiar user experience. The latest version brings a host of new features ranging from Apple M1 chip support and an interface update to new drawing options and control over your workflow.

Version 8.0

Apple Silicon Support

MacDraft runs natively on Macs powered by the Apple Silicon chips, for powerful and unrivalled performance. MacDraft Pro is now future-proof and ready for new machines and technologies that Apple may release, including M1 and M2 machines with Pro/Max Silicon Chips.

Version 8.0

Improved Interface

With the release and update that came with macOS Big Sur, MacDraft has had a welcome interface update. Utilising the intuitive design of the previous version, with some welcome tweaks and improvements around its performance.

Version 8.0

Larger Drawing Size

We have now increased the drawing size to a massive 1780 by 1780 inches. This means that you can create those huge and complex drawings without worrying about the document size. DWG compatibility has improved with the document size.

Version 8.0

Custom Workflow

Manage your workspace by choosing either palettes or a single screen. You’ll also be able to change from Dark and Light mode seamlessly. In addition you’ll find a refreshed and updated preferences with more options for customizing your MacDraft experience.

Version 8.0

Text Flow

Page layout and text control has never been easier with the new Text Flow features. Seamlessly flow text from one text box to another, allowing you to create flowing columns of text quickly. You can also control text preference options for fonts, styles and sizes.

Version 8.0

Spell Check

Spell check now works dynamically across the whole document. Any text elements in your drawings will now be included when you choose to check the spelling, which gives you the confidence that your text blocks are perfect for sharing with others.

Version 8.0

Export PDF

The all new Export PDF panel allows you to choose how the content in your drawings are exported. You can export the content only, the whole page (including the empty space) or even a multi page document for page layouts, making it quick and easy to control how PDF’s are exported.

Version 8.0

New Library

We know the powerful symbol library system is integral to the speed and efficiency of your designs. With this in mind we have redesigned the look and functionality of the Library, allowing you to have it separate to the rest of the interface and navigate faster.

Version 8.0

Trim Arcs & Curves

You’ve been requesting it and now it’s here. You can trim between arcs and arcs, arcs and curves, lines and arcs, lines and curves and much, much more. This makes the Trim tool far more superior and gives you all the power you need to quickly generate your drawings.

Version 8.0

Extend Arcs

Again, another hugely requested feature is the improvement of the Extend tool. The improvements will now allow you to extend lines to arcs, arcs to other arcs and even more importantly you’ll be able to extend lines and arcs to complex Bezier curves.

Version 8.0

Snapping

We have put in a highly requested feature for dragging shapes by their editing vertices. Now you can hold the Command (Apple) key and Option key down and drag an object by its handle to snap the vertices to another objects vertices for more precision and control.

Version 8.0

Line Thickness

At the heart of the drafting and design is the ability to communicate each part of a drawing. Now with MacDraft 8 you’ll have complete control to set a custom line thickness. You can set decimals as well as whole numbers between 0pt and 13pt line thickness.

Version 8.0

Swatch Panel

The Swatches is the perfect place to manage and control your colors, patterns and gradients. We have now added the ability to apply your colors, patterns and gradients via the Swatches panel, making it the most intuitive place to control you design attributes.

Version 8.0

French Localization

With the help of a native speaking French team, we have fully localised the MacDraft application to French.

Please note, that any PDF or online documentation, as well as help and technical support is only available in English at this time.

Version 8.0

Super/Subscript

Turn your text into Superscript (small text above) and Subscript (small text below) quickly and easily using the Text Transformations menu item. This brings more control to the MacDraft text options, secifically for annotations, footnotes, equations and more.

Version 8.0.1

macOS Ventura

Are you looking to upgrade your OS to Ventura? Rest assured that MacDraft 8 runs smoothly and effectively on the latest Mac Operating System. Design with confidence and harness your machines power and boost your productivity by running macOS Ventura and MacDraft 8.0.1 together.

Version 8.0.1

Extended Pen Style

We have created a fourth Pen Style, which is called Extended. This pen style will extend the line beyond the editing handle by half the line thickness. This means if you align two lines at a right angle and then use the Extended Pen style, you will get a perfect corner.

Version 8.0.1

Print the Grid

You’ll now find an option in the Print dialog that allows you to choose to print the grid. So whether you have opted for a traditional Dotted grid or the graphical style Square grid, you can now include it in the printing of your documents, making referencing easier.

Version 8.0.1

New Toolbar Items

We have added some new toolbar items to help improve your workflow and making it faster for you to locate the options you need. Options can be added to the toolbar at any time and once added they will be remembered each time you open MacDraft.

Version 8.0.2

macOS Sonoma

Are you looking to upgrade your OS to Sonoma? Rest assured that MacDraft 8 runs smoothly and effectively on the latest Mac Operating System. Design with confidence and harness your machines power and boost your productivity by running macOS Sonoma and MacDraft 8.0.2 together.

Version 8.0.2

Automatic Updates

Included in the latest version is a built in update system that will automatically check to see that you are running the latest version. If a newer minor version is available, the system will show you the release notes and prompt you to download and install the free update automatically.

Version 8.0.2

Measure Tool

The measure tool allows you to click on a single point on the drawing and drag a measuring line out that tells you the length of the measurement as you drag. Quickly and easily measure parts of your drawing, to determine size and scale, giving you a quick reference tool for your content size.

Version 8.0.2

Zoom Shortcuts

You can now control the zooming in and out of your drawings using the Command + and Command - keyboard shortcuts, giving you a more familiar way of zooming.

Version 8.0.2

DWG & DXF Scales

We have made some improvements to the way that scales are read and displayed when opening your AutoCAD DWG and DXF files. The correct scale will now be displayed when working with custom scales and the document will update its units automatically, to match the scale.

Version 8.0.2

Library Preview

The preview image created for your library items has been improved. Text now displays correctly with respct to the object it is connected to, the quality of the image has been improved up to 2 times and the content displays correctly when objects are drawn at different scales and zooms.

Version 8.0.2

Dual Monitors

We have included some important improvements to dual monitor compatibility. You can now use additional monitors to display your palettes when using palette mode and MacDraft will remember the palette positions for when you choose to use the dual monitors again.

Version 8.0.2

PDF Quality

When exporting your PDF documents we have improved the way that the content is displayed, giving you a more accurate and precise vector representation of your drawings. This means that when sharing your files, you have the confidence that your PDF contains all the correct content.

Version 8.0.3

LATEST

Edit Line Styles

Improvements have now been made to the Edit Line Style dialog, making it possible to edit and update your custom lines styles. You can now create your own custom styles, or simply update and edit the existing ones, using the familiar Edit Line Styles system.

Version 8.0.3

LATEST

macOS Sequoia

Are you looking to upgrade your OS to Sequoia? Rest assured that MacDraft 8 runs smoothly and effectively on the latest Mac Operating System. Design with confidence and harness your machines power and boost your productivity by running macOS Sequoia and MacDraft 8.0.3 together.

What is MacDraft and who is it for? Design anything with intuitive toolsets.

MacDraft is a 2D CAD drafting software that architects, engineers and construction professionals as well as designers, educators and hobbyists rely on to create precise 2D drawings on their Mac. MacDraft is packed full of industry-leading CAD tools allowing you to work more effectively and design with confidence. See the drawing examples below.

Compare MacDraft Packs

Powerful options for perfecting your drawings

The collection of powerful and flexible drawing options in MacDraft Pro lets you edit the parts of your drawings in any way you want. With full support for text and font management, a collection of precise adjustments for dimensions, fully scaled layers and vibrant controls for colors, patterns and gradients, it couldn’t be easier to produce professional 2D CAD drawings in minutes.

See a full list of features

Complete control with a fully scaled drawing environment

Use English and Metric scales to control the how your objects are viewed in relation to the page size. This gives you more precision when working on complex and larger drawings spaces, such as site plans, architectural elevations and more.

Precise and easy dimensions to markup your drawings.

Add smart dimensions to your CAD layouts using the intuitive and precise dimension system. Take full control over the way your dimensions display and information included. In addition, you can link your dimensions to their respective objects.

Scaled layers, make complex documents easy to manage

Layers are a great way to manage the content in your drawings. Each layer allows you to overlay content without effecting the objects in other layers. Take full control of your drawings and manage layers using an intuitive Layers panel.

Manage materials easily with colors, swatches and patterns.

Control all your colors, patterns and gradients using an integrated and intuitive swatch system. Manage, create and edit your swatches using an easy-to-use swatch panel, combined with our custom pattern and gradient editing.

Flexible drawing tools to bring your 2D CAD drawings to life.

MacDraft Pro has a comprehensive list of features, tools and options available to you. These will provide a smooth, fast and creative design experience, giving you the confidence to create your 2D CAD drawings, plans, engineering layouts, technical illustrations and much more. It has never been easier to design and layout your 2D CAD designs and MacDraft Pro’s vector tools and options give the intuitive and familiar feel of an easy to use 2D CAD drafting app.

See a full list of features

Vector shapes and curves

Easy to use drawing tools for Shapes, Lines & more. Whatever your project, rest assured MacDraft has a tool to help you along your journey. Take control and start designing with the help of MacDraft’s intuitive and dynamic drawing tools!

Advanced drawing tools

Working with complex designs requires a set of advanced tools. MacDraft includes a number of complex tools for breaking and joining lines, linking and unlinking dynamic objects, trimming and extending , creating a fillet or chamfer and more.

Smart and precise dimension tools

At the heart of MacDraft is its smart and precise units system, which makes dimensioning your drawings quick and easy. The dynamic and linked dimensioning system allows you to dimension any part of your drawing with the simple click of the mouse.

Get started quickly with 100’s of built-in templates

MacDraft offers a huge list of built-in templates to help you get started with drawing many different designs and layouts. Whether you’re looking to create a drawing from scratch; need a helping hand with your architectural and engineering layout; or planning a vector drawing project; MacDraft Pro has useful and professionally drawn templates for every occasion. You can even store you own templates in this panel, to make it easier for you to manage your documents.

An integrated Library system. Up to 7500 symbols available

MacDraft Pro includes a sophisticated and easy to use library system, where you can drag and drop commonly used items into your documents. As part of this Library system there is a fully-functioning database built in that links object data, such as name, material and other custom categories, to the objects stored in the library. You can then use this data to produce useful reports.

Compare MacDraft Packs

Customize your workflow for a personalized experience

MacDraft Pro gives you options to control how you layout your user interface, giving you complete control for a more personalized experience. Choose to use the more modern single screen to keep all of your window elements together or work with traditional floating palettes allowing you to move elements around (great for multiple screens). In addition you can customize the colors of your controls through system preferences, choose to use a dark or a light interface and choose how the grid, guides and document background displays.

Fully scaled drawing environment for architectural and floor plan design

Whether you’re a novice or a seasoned draftsmen, architectural and floor plan design is quick and easy in MacDraft Professional. Combining powerful and precise drawing tools with thousands of pre-drawn symbols and graphics, you’ll be creating your floor plans in a matter of minutes. With a comprehensive number of professional level tools, such shapes, lines and curves, even complex toolsets for datum management, linking and dimensioning, MacDraft Pro has all the features needed for all drawing types. Print, export, share and collaborate.

See a full list of features

Fast and easy dimensions

At the heart of MacDraft is its smart and precise dimension system. Dimensions are quick and easy and are the best way to communicate real-world sizes. MacDraft Pro gives a range of dimensions tools as well as formatting and tolerance options.

Fully scaled drawing system, powered by smart units

Scales are a great way to draw larger designs onto a smaller page, while maintaining the size and proportion of your drawings. You’ll find a whole set of useful default scales to use, in both English and Metric units or simply create your own custom scale.

Smart snap and alignment control

The Smart Snap feature gives you complete control over the positioning of your objects and groups with relation to other items in the document. Quickly snap to the edges and centers with intuitive and precise snap guides. Combine the Smart Snap feature with the vertices alignment for complete control.

Pinpoint accuracy with smart systems for engineering and technical layouts

Combining the smart scaling and dynamic unit systems MacDraft Pro’s layer system gives you the full control over the scales you use. Use layer scaling to produce working drawings, with sectional views and exploded diagrams. Increased accuracy allows for easy creation of intricate circuit diagrams and cutaway drawings. Drop in document guides for easy and pin-point positioning, accuracy and snapping. Finally manage drawings with advanced AutoCAD DWG support for opening, saving and editing.

See a full list of features

Guides are a great way to control the position and alignment of objects across a page. They can help when creating layout documents, CAD drawings, engineering plans and more. What’s more, the guides are non-printable, so will not interfere with your finished design export.

DWG support

Collaboration and cross application compatibility. DWG and DXF files are supported up to the latest AutoCAD 2022 (AC1032), allowing you to save, edit and open these file versions with options.

Layer scaling

Layers are important in any technical drawing and MacDraft Pro gives full control over the scales each layer has assigned. Individual layer scaling allows for pinpoint accuracy and intricate designs, such as sectional drawings, circuit diagrams and more. Plus you can add multiple drawing types to a single layout, simply by choosing a working layer scale.

Gorgeous garden and landscape designs, with built-in symbols

MacDraft Pro makes it easy to design and layout beautiful and vibrant landscape and garden plan designs. Combine ease of use with thousands of pre-drawn symbols and graphics, and start creating your landscape and garden plans in a matter of minutes. Add shapes, lines and sections then drag and drop plants, trees and structures from a large library of garden plan symbols and components. You can even store your own symbols using the full-featured custom library catalog.

See a full list of features

Export as PDF

Share and collaborate with your colleagues, friends and family. Export your drawings as a PDF and other common image formats to communicate your design ideas.

1000’s of pre-drawn library items

Bring designs to life with vibrant trees and plants, gorgeous structures and furniture and oar-inspiring patio, stone and wood materials.

Informative site plans using traditional drawing methods

Draw precise and intricate topographical maps, charts and more on your Mac with MacDraft Pro. Layout street maps, land formations and intricate plans with MacDraft Pro’s precise and easy to use vector drawing tools. Combine the power of a fully-scaled drawing environment with the familiarity of a vector based drawing app and advanced duplication to map out your ideas and create professional results. Couple all of this with the linked database of object information and reporting for a more collaborative approach.

See a full list of features

Advanced Duplication

MacDraft Pro offers traditional duplication methods coupled with more advanced techniques for Circular Duplication and Linear Duplication. Generate complex variants and precise grids when duplicating your shapes.

Object info and reporting

Every object in MacDraft Pro can have object information added to it. Examples are name, price, material and any other custom data you would like to use. This can then be integrated into the database and used to produce reports such as a bill of materials.

Design stunning illustrations and layouts with dynamic shapes and text

Let your imagination run wild, MacDraft will do the rest. Combine curves, gradients and opacities to create beautiful, cool and vibrant vector graphics in MacDraft. Whether its a logo, poster, brand or just a fun idea you’ve had, MacDraft gives you the chance to put pen to paper (or cursor to document layout) and let your skill and creativity take over. Getting stuck? We have thousands of breathtaking graphics available to you in the form of our graphics library add ons, simply drag and drop objects into your designs or create your own library of regularly used graphics for a future project! Your only limitation is your own imagination.

See a full list of features

Familiar curves, shapes and vector drawings tools

With a huge number of familiar vector drawing tools, such as shapes, lines and complex curves, MacDraft Pro has everything you’ll need to produce vibrant illustrations and stunning page layouts.

Advanced shape creation with Add, Remove and Cutting

Utilise the advanced drawing tools in MacDraft Pro for trimming, and extending lines. You’ll also find complex shape creation quick and easy using the boolean tools for adding and removing material from intersecting shapes.

Text, font and flow management

As well as the standard text formatting options MacDraft Pro includes an advanced layout features for flowing text from one textbook to another, using the clipped text warning. In addition you can turn any text object into vector shapes for the creation of stunning icons, symbols and branding.

Create your own scalable colors, patterns and gradients

MacDraft Pro comes with a selection of colors, gradients and patterns that you can use to bring your designs to life. I addition to the existing swatch selection, you’re also able to create your own unique material patterns in black and white or color, as well as your own gradients and colors. Our built-in scaling system will duplicate and format your patterns and gradients with ease, keeping your materials displaying the way they should. You’ll also find a range of additional swatches in the exclusive MacDraft Pro packs.

See a full list of features

Unlimited swatches

Create as many colors, gradients and patterns as you want. You can build new ones from scratch or take an existing one and make adjustments. Manage all from one intuitive Swatches panel.

Pattern Editor

The pixel pattern editor boast a range of options for creating pixel perfect, scalable patterns. Use colors or create traditional CAD materials from floors and walls to metals and liquids. You can also paste an image from an outside source into the editor to create more complex patterns.

Built for macOS. Powered by the latest Mac technologies

MacDraft Pro boasts incredible power with its highly sophisticated and incredibly precise drawing engine. It’s been designed and built to take full advantage of the full power of Mac computers, using advanced Mac vector graphics technologies such as Core Graphics and Core Image. Innovating for the future MacDraft Pro also includes full support for M1 chips, 64 bit systems and is built using Swift.

64-Bit Application

Gives the full power of your machine and is fully compatible with future operating systems.

M1 & M2 Compatibility

MacDraft Pro runs natively on Macs powered by the Apple Silicon chips, for powerful performance.

Built with Swift

An image processing and analysis technology that provides high-performance processing.

Block GCD

A technology used to optimize application support for systems with multi-core processors.

Swift UI

The application UI has been written on latest Swift v4 code for use of modern technologies.

Color Sync

A platform-independent color management system provided by the Apple system.

Core Image

Swift is a robust and intuitive programming language, built for reliability and efficiency.

Core Graphics

Based on the Quartz advanced engine, providing low-level, lightweight 2D rendering.

Core Text

A framework that provides modern, low-level programming for laying out and handling text.

Auto Layout

Technology for automatically adapting to different screen sizes and orientations.

Image I/O

Programming framework that allows applications to read and write most image formats.

Quartz

A framework that allows users to browse, edit, and save images, using Core Image filters.

QuickLook

A quick preview feature that allows you to view the content of a document without opening.

Dark/Light Mode

Integrating MacDraft with the System for changing between a light and dark interface layout.

Auto Save

Automatically saving open documents to preserve user data and protect against data loss.

Industry-leaders love MacDraft and we’re sure you’ll love it too!

MacDraft has an average worldwide rating of 4.5 stars out of 5. Partnered with Capterra, MacDraft users have given us top marks in all areas. It also has a Mac Informers award, boasting and Editors Pick badge. We know you’ll love MacDraft Pro - but don’t just take our word for it.

2021

MacDraft Pro

Highlighted as Editors Pick by Mac Informers.

Rated 4.5 out of 5 worldwide.
Read reviews

Choose your perfect MacDraft Pro

There are 4 main choices for MacDraft Pro and the choice you make depends on your needs. The Home and Garden, Starter and Complete packs contain exclusive library content. Take advantage of the content in the packs and choose the best MacDraft for you.

Compare all MacDraft packages

MacDraft Professional

$499.00£429.00€479.00 /Mac

Professional 2D CAD software for Mac. With specialised tools for architectural drawing, construction, engineering layouts, electronic diagrams and more.

Learn more

Buy

MacDraft Professional Home & Garden Bundle

$529.00£449.00€499.00 /Mac

Professional 2D CAD software bundle on the Mac, designed for interior, garden, landscape and hospitality plans. Includes MacDraft Pro and over 1100 symbols.

Learn more

Buy

RECOMMENDED

MacDraft Professional Starter Bundle

$599.00£499.00€569.00 /Mac

Perfect 2D CAD software bundle, to start with MacDraft Pro for architectural, mechanical and electrical. Includes MacDraft Pro and over 3500 symbols.

Learn more

Buy

MacDraft Professional Complete Bundle

$699.00£599.00€669.00 /Mac

An all-in-one 2D CAD bundle for Mac, for all your architectural, construction, engineering drawings and more. Includes MacDraft Pro and over 7500 symbols.

Learn more

Buy
